    2400-3000MHz Current Controlled Oscillator Voltage Controlled Sine Wave Generator

    Ask Lasest Price
    Brand Name : RFint
    Model Number : YSGM252708
    Price : Prices are negotiable
    Delivery Time : 2-10days
    Payment Terms : T/T,Western Union,MoneyGram
    • Product Details
    • Company Profile

    2400-3000MHz Current Controlled Oscillator Voltage Controlled Sine Wave Generator

    INNOTION 100% New 2400-3000MHz VCO 8dBm Voltage Controlled Oscillator Chip for Electronic Components Standard Package

    Product Description

    YSGM252708 is a highly integrated, standard package size VCO, using a high cut-off frequency RF transistor as an oscillating tube with high output power and good isolation. This VCO uses high stability oscillation circuit structure, high precision varactor diode and high output power RF Triode to ensure stable starting waveform and high output power. The system is supplied by 5V standard voltage, and the tuning voltage can be up to 9V, thus the broadband output can be realized.


    Characteristic parameter

    Nominal tuning frequency band2500~2800MHz@VT=0.5V~4.5V
    Output power≥8dBm @VCC=5V
    In-band flatness (BW≤200MHz)±0.5dB
    Power supply voltage (VCC)3V ~ 9V
    Working current15mA~30mA
    Second harmonic suppression≤-30dBc
    Third harmonic suppression≤-35dBc
    Radio-frequency output impedance50Ω
    Universal package size7mm x 9mm x 2mm


    2400-3000MHz Current Controlled Oscillator Voltage Controlled Sine Wave Generator
    2400-3000MHz Current Controlled Oscillator Voltage Controlled Sine Wave Generator

    Packing & Delivery
    To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
    Company Profile
    Zhongshi Zhihui Technology (suzhou) Co., Ltd. is located in Suzhou Industrial Park, founded in 2010, the company is mainly engaged in, and can provide customers with wireless communication network coverage solutions of high-tech enterprises. The company implements radio-oriented development strategy based on radio frequency technology, independent research and development and production of bidirectional frequency conversion super WiFi signal amplifier products, radio frequency and microwave voltage controlled oscillator (VCO), sweep signal source, wireless network card information security module and other product lines, has mastered some core technologies in the product field, has a lot of independent intellectual property rights.
    FAQ
    1. who are we?
    We are based in Jiangsu, China, start from 2010,sell to Western Europe(50.00%),Southern Europe(12.00%).

    2. how can we guarantee quality?
    Always a pre-production sample before mass production;

    Always final Inspection before shipment;

    1 year warranty for our products.


    3.what can you buy from us?
    Signal Booster, VCO, Anti Drone Jammer Module, Power Amplifier, Gain Block and so on
