Zhongshi Zhihui Technology (suzhou) Co., Ltd.
1 Years
| Ask Lasest Price | |
| Model Number : | YP3035W |
| Brand Name : | RFint |
| Price : | Prices are negotiable |
| Delivery Time : | 2-10days |
RFint 100% New Network Wireless Lan Power Amplifier YP3035W 2.4GHz Three-Stage Linearized Optimized For 802.11b/g/n WLAN
The YP3035W is a three stage linearized power amplifier optimized for 802.11b/g/n WLAN applications in the 2.4GHz band. The device is manufactured on an advanced InGaP Heterojunction Bipolar Transistor (HBT) process,The amplifier provides a typical gain of 30 dB and P1dB power of 34.5dBm, typical bias condition is 5V at 450 mA. The YP3035W is assembled in a 16-pin, 4 x 4mm2, QFN package. It is internally integrated with ESD protection circuitry on all ports.
Features
| Frequency Range: | 1.8~2.8GHz |
| Operation Voltage: | 3.3V~5.0V |
| Gain (Typ) | 30dB |
| Quiescent Current | 450mA |
| Input Return Loss | >20dB |
Zhongshi Zhihui Technology (suzhou) Co., Ltd. is located in Suzhou Industrial Park, founded in 2010, the company is mainly engaged in, and can provide customers with wireless communication network coverage solutions of high-tech enterprises. The company implements radio-oriented development strategy based on radio frequency technology, independent research and development and production of bidirectional frequency conversion super WiFi signal amplifier products, radio frequency and microwave voltage controlled oscillator (VCO), sweep signal source, wireless network card information security module and other product lines, has mastered some core technologies in the product field, has a lot of independent intellectual property rights.
Always final Inspection before shipment;
1 year warranty for our products.
|
|
