    280-380MHz 9dBm Coaxial Resonator Oscillator Standard Features Customized

    Ask Lasest Price
    Brand Name : RFint
    Model Number : YSGM030408
    Price : Prices are negotiable
    Delivery Time : 2-10days
    Payment Terms : T/T,Western Union,MoneyGram
    • Product Details
    • Company Profile

    280-380MHz 9dBm Coaxial Resonator Oscillator Standard Features Customized

    Innotion 100% New VCO 280-380MHz 9dBm Voltage Controlled Oscillator Standard Features for Customized

    Product Description

    YSGM030408D is a highly integrated, standard packaged broadband voltage-controlled oscillator (VCO) product.The improved Colpitts oscillation circuit structure and integrated buffer are adopted, which has the advantages of stable oscillation, good isolation and high output power.


    Nominal tuning frequency band280 ~ 380MHz@VT=0V~5V
    Output power≥9dBm(VCC=5V)
    In-band flatness (BW≤200MHz)±0.5dB
    Power supply voltage (VCC)3V ~ 6V
    Working current12mA
    Second harmonic suppression≤-20dBc
    Third harmonic suppression≤-30dBc
    Radio-frequency output impedance50Ω
    Universal package size7mm x 9mm x 2mm

    280-380MHz 9dBm Coaxial Resonator Oscillator Standard Features Customized

    280-380MHz 9dBm Coaxial Resonator Oscillator Standard Features Customized

    Packing & Delivery
    To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
    Company Profile
    Zhongshi Zhihui Technology (suzhou) Co., Ltd. is located in Suzhou Industrial Park, founded in 2010, the company is mainly engaged in, and can provide customers with wireless communication network coverage solutions of high-tech enterprises. The company implements radio-oriented development strategy based on radio frequency technology, independent research and development and production of bidirectional frequency conversion super WiFi signal amplifier products, radio frequency and microwave voltage controlled oscillator (VCO), sweep signal source, wireless network card information security module and other product lines, has mastered some core technologies in the product field, has a lot of independent intellectual property rights.
    FAQ
    1. who are we?
    We are based in Jiangsu, China, start from 2010,sell to Western Europe(50.00%),Southern Europe(12.00%).

    2. how can we guarantee quality?
    Always a pre-production sample before mass production;
    Always final Inspection before shipment;

    1 year warranty for our products.


    3.what can you buy from us?

    Signal Booster, VCO, Anti drone jammer module, Power Amplifier, Gain Block and so on
