Stable Output Power 8dBm Analog Devices Vco For PCBA Integrated Circuit Chip

Stable Output Power 8dBm VCC 5V VCO 4800-5600MHz Voltage Controlled Oscillator for PCBA Integrated Circuit Chip

Product Description

YSGM556006 is a highly integrated, standard package size VCO with two-stage transistor Cascade structure, low working current, high output power and good isolation.
This VCO uses a new high-frequency oscillation circuit structure, high-precision varactor diode and high cut-off frequency radio frequency Triode to ensure the stability of the starting waveform and good consistency of the oscillation frequency band.
The system is supplied by 5V standard voltage, and the tuning voltage can be up to 9V, thus the broadband output can be realized.

Characteristic parameter

Nominal tuning frequency band	4950~5350MHz@VT=0.5V ~ 4.5V
Output power	≥8dBm @VCC=5V
In-band flatness (BW≤200MHz)	±0.5dB
Nominal tuning frequency band	4800~5600MHz@VT=0V ~ 9V
Power supply voltage (VCC)	3V ~ 9V
Working current	15mA~30mA
Second harmonic suppression	≤ -30dBc
Third harmonic suppression	≤ -35dBc
Radio-frequency output impedance	50Ω
Universal package size	7mm x 9mm x 2mm

Stable Output Power 8dBm Analog Devices Vco For PCBA Integrated Circuit Chip
