| Brand Name : | RFint |
| Model Number : | YSGM404506 |
| Price : | Prices are negotiable |
| Delivery Time : | 2-10days |
| Payment Terms : | T/T,Western Union,MoneyGram |
YSGM040506 is a highly integrated, standard package size VCO, using
a high cut-off frequency RF transistor as an oscillating tube with
high output power and good isolation.
This VCO uses high stability oscillation circuit structure, high
precision varactor diode and high output power RF Triode to ensure
stable starting waveform and high output power.
It adopts 5V standard voltage, which is compatible with the working
voltage in the range of 3V and 6V, and has a wide tuning voltage
range, which can realize the output of wide band and high power.
| Nominal tuning frequency band | 4000~4550MHz@VT=0V~5V |
| Output power | ≥8dBm @VCC=5V |
| In-band flatness (BW≤200MHz) | ±0.5dB |
| Power supply voltage (VCC) | 3V ~ 6V |
| Working current | 14mA |
| Second harmonic suppression | ≤ -20dBc |
| Third harmonic suppression | ≤ -25dBc |
| Radio-frequency output impedance | 50Ω |
| Universal package size | 7mm x 9mm x 2mm |
Always final Inspection before shipment;
1 year warranty for our products.
|
|
