SZHUASHI 80W 28 V 0.7-6.2GHz Signal Power Amplifier For Wired LAN
Network And Typical VDS for 700MHz-6200MHz
YPM07620880M is a 80-watt, internally 50ohm matched GaN HEMT,
designed specifically with high efficiency, high stability and wide
bandwidth capabilities, which makes the YPM07620880M ideal for
700MHz~6200MHz, CW amplifier applications.
Features
Suitable for linear and saturation applications | Pout=80W, CW |
Typical VDS:28 V | Freq Range:0.7-6.2GHz |
Excellent Thermal Stability and Excellent Ruggedness | 100% RF tested |
Negative Gate Voltage and Bias Sequencing Required | RoHS |
